Garmin BlueNet 20 Switch

Specifications

Garmin BlueNet 20 Switch Specs

• Material: Polycarbonate plastic and die-cast aluminum
• Dimensions (W x H x D): 293.3 × 72 × 112.6 mm (9 7/16 × 2 13/16 × 4 7/16 in.)
• Weight: 0.5 kg (1 lb. 2 oz.)
• Operating temperature range: From -15° to 70°C (from 5° to 158°F)
• Water rating: IEC 60529 IPX71
• Power input: From 10 to 32 Vdc, 2 A max.
• Fuse: 2 A
• Max. power usage: 3.6 W
• Typical current draw 12 Vdc: 270 mA
• 24 Vdc: 140 mA
• Max. current draw: 330 mA
• Compass-safe distance: 10 cm (4 in.)
